Product Introduction
The laser welding machine is an advanced tool that joins metals or thermoplastics using a focused laser beam. It provides deep, precise welds with minimal heat input and distortion. Laser welding is fast, clean, and suitable for both thin and thick materials. It supports spot welding, seam welding, and complex joint geometries. The process is non-contact, reducing wear and contamination. AccTek Group’s laser welding machines are designed for high-speed, high-precision applications in automotive, aerospace, electronics, medical, and metal fabrication industries. They offer excellent repeatability, low maintenance, and easy integration into automated systems. Our machines can handle stainless steel, carbon steel, aluminum, titanium, and more. With handheld and robotic models available, they adapt to both manual and automated workflows. Built with smart control systems and user-friendly interfaces, AccTek Group’s laser welding solutions deliver stable performance, strong welds, and high production efficiency, making them a reliable choice for modern manufacturing.
Types of Laser Welding Machines
-
Standard Handheld Laser Welding Machine
$4,400.00 – $8,600.00 This product has multiple variants. The options may be chosen on the product page -
Portable Handheld Laser Welding Machine
$3,700.00 – $15,500.00 This product has multiple variants. The options may be chosen on the product page -
3 in 1 Handheld Laser Welding Machine
$4,000.00 – $15,700.00 This product has multiple variants. The options may be chosen on the product page -
Double Wobble Handheld Laser Welding Machine
$4,900.00 – $9,100.00 This product has multiple variants. The options may be chosen on the product page -
Double Wire Feed Handheld Laser Welding Machine
$6,800.00 – $15,800.00 This product has multiple variants. The options may be chosen on the product page -
Air-Cooled Handheld Laser Welding Machine
$4,900.00 – $6,900.00 This product has multiple variants. The options may be chosen on the product page -
3 in 1 Air-Cooled Handheld Laser Welding Machine
$5,100.00 – $7,100.00 This product has multiple variants. The options may be chosen on the product page -
Automatic Laser Welding Platform
$9,800.00 – $21,500.00 This product has multiple variants. The options may be chosen on the product page
Application of Laser Welding Machines
Laser welding machines are used across a wide range of industries for their speed, precision, and versatility. In automotive manufacturing, they weld car bodies, battery packs, and structural components. In aerospace, they join high-strength alloys and precision parts with minimal thermal distortion. In electronics, they handle micro-welding tasks for sensors, circuit boards, and enclosures. Medical device manufacturers use them for stainless steel instruments, implants, and surgical tools. In metal fabrication, they weld frames, panels, tubes, and custom parts with clean, strong seams. Jewelry makers rely on laser welding for fine, detailed joins without affecting surrounding areas. The energy sector uses them for battery modules, solar components, and metal housings. Laser welding is ideal for stainless steel, aluminum, titanium, copper, and other metals. AccTek Group’s machines support both handheld and automated use, making them suitable for small workshops and large production lines. Their precision and reliability improve product quality and reduce rework.
Customer Testimonials
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.
Laser Welding Machine VS Other Welding Machines
| Comparison Item | Laser Welding Machine | TIG Welding Machine | MIG Welding Machine | Stick Welding Machine | Plasma Arc Welding Machine |
| Heat Input | Low | Low | Medium | High | High |
| Precision | Very high | High | Medium | Low | Medium |
| Welding Speed | Fast | Slow | Fast | Medium | Fast |
| Material Distortion | Minimal | Low | Moderate | High | High |
| Joint Strength | High | High | High | Medium | High |
| Automation Compatibility | Excellent | Limited | Moderate | Low | Moderate |
| Thickness Range | Thin to thick | Mostly thin | Medium to thick | Medium to thick | Thin to medium |
| Aesthetic Finish | Clean, minimal post-processing | Very clean | Acceptable | Rough | Rough |
| Operator Skill Requirement | Low to moderate | High | Moderate | Moderate | High |
| Consumables Required | Minimal | Tungsten electrodes | Wire + gas | Electrodes | Electrodes + gas |
| Welding Method | Non-contact | Contact | Contact | Contact | Contact |
| Material Compatibility | Wide (including reflective metals) | Limited | Good for steel & aluminum | Best for steel | Limited to conductive materials |
| Portability | High (handheld options available) | Medium | Medium | High | Low |
| Operating Cost | Low (after setup) | High (due to slow speed) | Moderate | Low | High |
| Ideal Applications | Precision, automation, clean welds | Aerospace, thin metals | Structural work, fabrication | Field repairs, basic welding | Thin materials, cutting+joining |
Why Choose Us
AccTek Group is a professional manufacturer of laser welding machines, delivering precise, efficient, and reliable welding solutions for a wide range of industries. Our machines are designed to meet the growing demand for high-strength, low-distortion welding in applications such as sheet metal processing, automotive manufacturing, electronics, and aerospace. We combine advanced laser technology with user-friendly design to help businesses improve welding quality, reduce labor costs, and boost production efficiency. Whether you’re handling fine parts or large-scale components, our systems offer the flexibility and performance needed to meet modern manufacturing standards. With a strong focus on quality, innovation, and customer support, AccTek Group is your trusted partner for laser welding solutions.
High Precision
Our machines deliver accurate, clean welds with minimal heat input, reducing distortion and ensuring strong, consistent joints across a wide range of materials and thicknesses.
Easy Operation
Designed with intuitive controls and user-friendly interfaces, our systems allow both experienced operators and new users to achieve professional results with minimal training.
Durable & Reliable
Built with high-quality components and strict quality standards, our welding machines provide stable performance, long service life, and low maintenance requirements.
Custom Options
We offer a variety of models and customizable features to match specific production needs, helping businesses improve workflow and adapt to changing manufacturing demands.
Related Resources
AccTek Group Debuts At BUTECH 2025
2025-04-10
AccTek debuts at BUTECH 2025, Busan, May 20‑23. See Booth E‑06: AKJ1530F1/FB fiber laser cutting machines, AKQ‑300 laser cleaning machine, AKQH‑3000 3‑in‑1 laser welding cleaning cutting machine, AKM1325C router.
What Is Oscillating Knife Cutting?
2025-03-10
Discover the precision, efficiency, and versatility of oscillating knife-cutting technology. Learn how it works, its advantages, its applications, and why industries rely on it.
What Is CNC Routing?
2025-03-10
Discover the fundamentals of CNC routing, its applications, advantages, challenges, and how advanced CNC technology enhances precision and efficiency across industries.
What Is Laser Marking?
2025-03-07
Discover the fundamentals of laser marking, its types, applications, advantages, and key considerations. Learn how this advanced technology enhances precision, durability, and efficiency across industries.
Frequently Asked Questions
What Is Laser Welding?
Laser welding is a highly precise welding technique that uses a focused laser beam to melt and fuse materials, typically metals, together. The laser generates intense heat, which melts the workpieces at the joint, allowing them to solidify and form a strong bond once cooled.
The process is popular for its ability to create narrow, deep welds with minimal heat-affected zone (HAZ), making it ideal for thin materials, high-precision applications, and complex geometries. It is commonly used in industries such as aerospace, automotive, electronics, and medical device manufacturing.
Laser welding can be done with different types of lasers, including fiber lasers, CO2 lasers, and disk lasers, depending on the material and application.
What Materials Can Laser Welding Machines Weld?
Laser welding machines are highly effective for welding various types of metal materials, including:
- Carbon Steel: Commonly used in construction, automotive, and manufacturing industries, carbon steel is easy to weld with lasers, especially for thick sections.
- Stainless Steel: Laser welding provides precise, clean welds on stainless steel, which is commonly used in the food, medical, and automotive industries due to its corrosion resistance.
- Aluminum: Aluminum welding requires careful control of the laser due to its high thermal conductivity, but laser welding is highly effective for aluminum components in the aerospace and automotive sectors.
- Copper: Laser welding of copper requires high precision due to its high reflectivity and thermal conductivity. However, it’s often used in the electrical and electronics industries.
- Titanium: Laser welding titanium is ideal for applications in the aerospace and medical industries, as it requires a clean, controlled environment to prevent contamination.
- Brass: Used in automotive and decorative applications, brass can be effectively welded using laser technology for precise results.
- Nickel Alloys: Laser welding is highly effective for nickel alloys used in aerospace and marine applications, providing strong, durable welds for high-stress environments.
- Gold and Platinum: For high-precision applications, such as in electronics or jewelry, laser welding is used to join gold and platinum with minimal heat input, maintaining their properties.
How Do I Determine The Laser Power Required For My Welding Application?
The laser power needed for welding depends on several factors, including the type of material, thickness, welding speed, and the quality of the weld required. Here’s how you can determine the power required for your application:
- Material Type: Different materials absorb laser energy differently. Metals like aluminum and copper require higher laser power than stainless steel or carbon steel due to their higher reflectivity and thermal conductivity.
- Material Thickness: The thicker the material, the more power you will need. For thin materials (less than 1 mm), lower-power lasers (typically between 1000W and 1500W) are sufficient. For thicker materials, especially in the range of 5 mm or more, you may need higher power (2000W to 6000W or more).
- Welding Speed: If you need to weld at a higher speed, you will typically need more laser power to ensure the weld is formed properly before the material cools. Slower speeds allow for more time for heat to be applied, reducing the need for higher power.
- Weld Quality Requirements: If you need high-quality, clean, and precise welds with minimal heat-affected zones, you may need to use lower power with slower speeds or specialized lasers for specific tasks (e.g., small welds, jewelry).
- Laser Spot Size: The spot size affects the energy concentration. Smaller spot sizes require higher power to achieve the same weld depth as larger spot sizes. Choose a laser with an appropriate spot size for the job.
What Joint Designs Are Best Suited For Laser Welding?
Laser welding is highly precise and works best with certain joint designs that allow for optimal energy absorption and heat distribution. The best joint designs for laser welding include:
- Butt Joints: Butt joints are one of the most common and effective joint designs for laser welding. The workpieces are placed edge-to-edge, creating a strong and continuous weld. This design is ideal for welding thin to medium thickness materials and provides excellent strength with minimal distortion.
- Lap Joints: Lap joints, where one workpiece overlaps the other, are also well-suited for laser welding. They allow the laser to focus on the overlap, making it easy to create a strong, clean weld. This design is useful for welding materials with different thicknesses and can be used in applications where precise alignment is important.
- T-Joints: T-joints are often used in structural and automotive applications. The laser can effectively weld along the joint where the two materials meet at a right angle. T-joints are ideal for welding medium to thick materials and provide high-strength welds.
- Edge Joints: Edge joints are commonly used for welding sheet metals and thin materials. The laser is focused along the edge of the material, making this design suitable for creating precise, narrow welds with minimal heat input.
- Flanged Joints: Flanged joints are used when materials are welded at a corner or edge. This joint design allows the laser to access both sides of the joint, making it well-suited for producing strong, clean welds with minimal distortion, especially in thicker materials.
- Corner Joints: Corner joints are used in the fabrication of frames, boxes, and other structures. When welded with a laser, these joints provide strong and durable results, especially when the materials have similar thickness.
- V-Groove Joints: V-groove joints are often used for thick material welding. The V-shape allows the laser to penetrate deep into the joint, ensuring full penetration and creating a strong bond. This design is ideal for welding materials with greater thickness or where deep penetration is necessary.
How Does Laser Welding Reduce Thermal Deformation Of Materials?
Laser welding is known for its ability to minimize thermal deformation compared to traditional welding methods. Here’s how it achieves that:
- High Precision and Focused Energy: The laser beam is highly focused, allowing the heat to be concentrated precisely at the welding point. This localized heating reduces the amount of heat transferred to the surrounding material, minimizing thermal expansion and distortion.
- Small Heat-Affected Zone (HAZ): Laser welding creates a narrow heat-affected zone (HAZ) around the weld, which means only a small area of the material is exposed to high temperatures. This limits the amount of material that undergoes thermal changes, reducing the risk of warping or deformation.
- Rapid Cooling: Laser welding typically involves rapid cooling after the laser pulse. This quick solidification of the molten weld pool reduces the time during which the material is exposed to heat, which in turn helps in maintaining the shape and structure of the material with minimal distortion.
- Lower Heat Input: Because laser welding uses a concentrated, high-power beam over a very short duration, the total heat input is much lower compared to processes like MIG or TIG welding. Lower heat input means less thermal expansion and contraction, which reduces the potential for distortion.
- Controlled Welding Speed: Laser welding allows for high-speed welding, which means the material stays under the heat source for a shorter time. This further helps to minimize thermal stresses and the likelihood of warping.
What Personal Protective Equipment Is Required When Using Laser Welding Machines?
When operating laser welding machines, safety is a top priority due to the risks of laser exposure, fumes, and intense heat. The required personal protective equipment (PPE) includes:
- Laser Safety Glasses or Goggles: Laser safety glasses are essential to protect the eyes from the intense laser radiation. These glasses are specifically designed to filter the wavelength of the laser being used, preventing eye injury from both direct and reflected beams.
- Protective Clothing: Flame-resistant, non-reflective clothing should be worn to protect against sparks, hot metal, and radiation. Long-sleeve shirts and pants, preferably made from thick cotton or specialized materials, are recommended to avoid burns.
- Gloves: Heat-resistant gloves are necessary to protect the hands from burns or heat exposure when handling metal parts during or after welding. For laser welding, gloves should also be designed to allow dexterity while offering sufficient heat protection.
- Welding Helmet or Face Shield: A welding helmet or face shield is needed to protect the face from intense light, radiation, and flying debris. These shields should be fitted with a lens that filters out harmful radiation, providing additional eye and facial protection.
- Respiratory Protection: If adequate fume extraction is not in place, respirators or dust masks with the appropriate filters (such as N95 or P100) should be worn to avoid inhaling harmful fumes, gases, or particulate matter generated during the welding process.
- Hearing Protection: High-powered lasers can generate loud noises during welding, especially in industrial environments. Earplugs or earmuffs may be necessary to protect hearing from prolonged exposure to high noise levels.
- Safety Footwear: Sturdy, steel-toe boots are recommended to protect the feet from falling equipment, sparks, and molten material that could cause injury.
Is It Necessary To Use Gas When Using Laser Welding?
The use of gas during laser welding is not always necessary, but it is often highly beneficial and sometimes essential, depending on the application. Gases are used to improve the quality of the weld and protect both the material and the machine. Here’s how:
- Shielding Gas
- Purpose: The most common reason for using gas in laser welding is to shield the weld area from contamination by atmospheric gases like oxygen or nitrogen.
- Common Gases Used: Argon, helium, nitrogen, and sometimes CO2 are typically used as shielding gases. Argon is the most common as it provides an inert atmosphere, reducing the risk of oxidation and porosity in the weld.
- Gas for Cooling
- Purpose: Some laser welding applications require a cooling gas to help control the heat distribution, especially when working with heat-sensitive materials like aluminum or titanium.
- Common Gases: Compressed air or nitrogen can be used to reduce excessive heat buildup and ensure proper cooling.
- Active Gases for Specific Applications
- Active gases like CO2 may be used in certain situations to promote chemical reactions during welding, such as cleaning oxides off the surface of metals or promoting specific weld properties.
- When Gas is Not Necessary
- In some laser welding setups (especially for high-precision or small-scale welding), using gas may not be necessary, particularly when working in controlled environments with minimal risk of contamination.
- For metal-to-metal welding in vacuum chambers or when working with low-alloy steels, gas may not be required.
What Are The Recommended Environmental Conditions For Laser Welding Machines?
Laser welding machines require a controlled environment to operate efficiently and safely. The recommended environmental conditions include:
- Temperature
- Optimal Range: The ambient temperature in the welding area should generally be between 18℃ to 25℃ (64℉ to 77℉).
- Avoid Extreme Temperatures: Extreme heat or cold can affect the performance of the laser and the material being welded. High temperatures can increase the risk of thermal distortion, while cold temperatures may cause poor weld penetration.
- Humidity
- Ideal Humidity: Humidity levels should be kept between 40% and 60%.
- Why it Matters: High humidity can cause condensation on equipment, leading to rust or electrical issues. Low humidity can cause static build-up, which can interfere with the precision of the laser.
- Ventilation and Air Quality
- Fume Extraction: Proper ventilation or fume extraction systems are essential to remove harmful fumes, gases, and particles created during the welding process.
- Clean Air: Ensure the workspace is free from dust, smoke, or airborne contaminants that may interfere with laser operation or damage sensitive components.
- Vibration Control
- Stable Environment: The welding area should be as free of vibrations as possible. Even slight vibrations can affect the precision of the laser, leading to poor weld quality.
- Proper Foundations: Ensure the laser machine is mounted on a stable, vibration-resistant surface to minimize movement during welding.
- Lighting
- Proper Lighting: The area should be well-lit but free from direct bright lights that could interfere with the laser beam’s accuracy.
- Avoid Reflections: Ensure the workspace is designed to minimize reflective surfaces that could redirect the laser beam and cause accidents.
- Cleanliness of the Workspace
- Dust-Free Environment: The work area should be kept clean and free from dust and contaminants. These could affect both the quality of the weld and the performance of the laser optics.
- Electrical Stability
- Consistent Power Supply: The area should have a stable electrical supply to avoid power surges, which can damage the laser system.
- Surge Protection: Install surge protectors to prevent damage from power fluctuations.
Get Laser Welding Solutions
Need stronger welds, cleaner seams, and faster production? Our laser welding solutions are designed for businesses that demand accuracy, efficiency, and long-term reliability. Whether you’re working with stainless steel, aluminum, copper, or more complex alloys, our systems deliver deep, consistent welds with minimal heat distortion and virtually no post-processing. From compact handheld units to high-powered automated setups, we offer solutions tailored to your workflow. You’ll reduce rework, cut downtime, and boost output—without sacrificing quality.
We’ll help you choose the right equipment, get it up and running fast, and support you every step of the way. Our team understands the real-world challenges of welding, and we’re here to make it easier, cleaner, and more productive. Talk to us today and get a laser welding solution that fits your operation—no guesswork, just results.
